Suzuki 5HP Outboard

Overview

The Suzuki DF5 is a compact, clean-burning 4-stroke outboard built for portability, smooth power delivery, and easy handling on smaller boats. It’s a strong choice for inflatable boats, tenders, and compact fishing setups where reliable performance and simple operation matter.

Key Benefits

• Lightweight, compact design for easier carrying, loading and storage
• Fuel-saving 4-stroke technology with smooth, dependable power
• Strong low-to-mid range torque and responsive acceleration from the 138cc single-cylinder design
• Digital CDI ignition for stable idling, precise timing control and a built-in rev limiter
• Tiller handle mounted on the steering bracket to help you sit forward for improved weight distribution
• 180-degree steering for excellent manoeuvrability, including in shallow water
• Integral fuel tank for a clean, self-contained setup

Key Features

• Advanced design focused on ease of operation and handling
• Single-cylinder OHV engine (138cc) delivering excellent usable torque in a portable package
• Integrated digital CDI ignition unit designed to resist corrosion and improve reliability
• Practical layout for balance and confident control on smaller craft
• Integral fuel tank (1.0L) and a large carrying handle for portability

Specifications

• Shaft Length: Short (381mm)
• Colour: Pearl Nebular Black
• Steering Type: Tiller
• Tilt: Manual
• Starter: Manual (pull start)
• Weight: 24kg

Dimensions and Prop

• Recommended Transom Height: 381mm (15in)
• Bore x Stroke: 60.4 x 48.0mm
• Propeller Selection (pitch): 6″ – 7″

Engine Specification

• Starting System: Manual
• Engine Type: OHV
• Fuel Delivery System: Carburettor
• Number of Cylinders: 1
• Piston Displacement: 138cc
• Maximum Output: 3.7kW
• Full Throttle Operating Range: 4,500 – 5,500 RPM
• Oil Pan Capacity: 0.7L
• Fuel Tank Capacity: Integral 1.0L
• Ignition System: Digital CDI
• Engine Mounting: Bushing Type
• Trim Method: Manual
• Gear Ratio: 1.92:1
• Gear Shift: F-N-R (Forward-Neutral-Reverse)
• Exhaust: Above Prop Exhaust

Oil Warning

All outboard motors undergo a Pre-Delivery Inspection (PDI). The engine is inspected and tested to ensure it runs as it should prior to shipping. After testing, the engine oil is drained as it can leak in transit. You must fill with the correct type and amount of oil before running your motor.

FAQs

Is this outboard suitable for inflatable boats?

Yes – the Suzuki DF5 is a great match for small inflatables and tenders thanks to its portable weight, tiller control and efficient 4-stroke performance.

Is it electric start?

No – this model is manual pull start.

Is a long shaft version available?

Yes – a long shaft option is available.

Does it have an internal fuel tank?

Yes – it includes an integral fuel tank (1.0L) for a simple, portable setup.

Do I need to add oil before first use?

Yes – the motor is tested during PDI, then the oil is drained to reduce leak risk in transit. Add the correct type and amount of oil before running the engine.

What kind of steering does it use?

Tiller steering, designed for straightforward control and manoeuvrability on smaller boats.

Shipping cost

There is a (Pre Delivery Inspection) and shipping charge for this item to mainland UK:

If shipping with a Hydrus then shipping will be:

Please let us know if you prefer to collect for FREE from Worthing, West Sussex or if you’d like to arrange your own delivery.

Please Note: Our warehouse is NOT open to the public.

For shipping overseas please contact us first.

Please see all our Shipping Fees here.

Other Engines

Other engines are available.

If you prefer long shaft or other makes and models simply Contact Us.
